Instrumentation Draft and Design Course

Course Description

You can easily learn about Instrumentation Draft and Design with the assistance of this course. In this course you will learn about:-

  • Inspection of system/equipments
  • Acquirement requirements
  • Well elaborated design of instrumentation systems that also include Layouts as well
  • Preparation ladder figure
  • Installation and maintenance tips related to all the instruments
  • Pressure, temperature and level
  • The different process conditions
  • Preparation drawings related to Hookup
  • Election of instruments for controlling pressure, level, temperature, and flow
  • Preface project design requirements
  • Power plant, Pharmaceutical industrial, Petrochemical etc
  • Requirement of basic designed based on Plant-type
  • Appropriate standards and codes

This course will be very fruitful for you if you like to make your career in this industry. Career opportunities are also very bright after completion of course. It is lesser time consuming than other courses and you will get more beneficial results with this course. You just need to pay complete focus on this course to gain the desired opportunity further.

Other Details

Additional information



Scheduled Date

25 Sept 2020


3 Months


10:00 AM – 4:00 PM
